Underground mines where low-profile transformers are found


Acutran designs and manufactures field-proven, low-profile mining duty transformers for a variety of mining environments and applications.

Mining duty transformers are used extensively at mines, converting and distributing voltage utilized for distribution, load center, and shovel duty. They must have high power, a low profile, and a compact design to be suitable for rugged mining locations.

Reliability and performance are critical for mining transformers, and control systems are becoming increasingly complex. That’s why major mining companies and mine service providers in North America trust the experts at Acutran for robust, rugged solutions for their power centers and power distribution systems.


Acutran dry-type mining transformers are custom engineered and manufactured for harsh mining environments, including:

  • Underground Mining
  • Surface Mining
  • Process Plants

Acutran Mining Transformer Features

Category Description
Power Rating 10kVA to 3000kVA
Voltages 7200V to 22000V
Frequencies 60 hz
Temperature Rise 150°C
Mounts Surface and skid
Classifications Hazardous and seismic areas
Enclosures Mild steel or stainless steel painted in Standard ANSI 61 grey or standard coast guard white. Indoor or Outdoor Application

Standards, Quality, and Requirements

Acutran is ISO9001:2015 certified and is a certified Veteran Owned Business. Our products are compliant with all current standards and industry requirements, including MSHA requirements.

sri logo

Custom Features


    • Equipment specifications
    • Main mine substations
    • Pit / perimeter subs
    • Portable switchgear
    • Generator sets / motivators
    • Capacitor banks
    • D-boxes / J-boxes
    • Dewatering skids / drives

Process plants

    • Medium voltage switchgear (up to 38KV)
    • MCCs / motor controls
    • Variable Frequency drives / soft-starts
    • Automation, PLCs, and Instrumentation


    • New mine electrical system design
    • Equipment specifications
    • Mine surface and underground substations
    • Power centers / load centers (section, belt, utility)
    • Long wall electrics and controls
    • Vacuum switch-houses/disconnects
    • Dry-type transformers
    • Capacitor banks
    • D-boxes / J-boxes
    • Belt and fan controllers (packaged soft starts or VFDs)
    • Mobile generator sets

Why Choose Acutran for Your Mining Applications?

For more than 35 years, the experts at Acutran have been designing and manufacturing dry-type transformers for critical power applications in the world’s most challenging mining environments. By using the highest quality raw materials for our comprehensive product range, partnering with our customers to help them succeed, providing excellent engineering support, and committing to on-time delivery every time, we make it easy for our customers to work with us.

Custom transformer quote and design within 48 hours
